Projection System

DLP

Resolution

4K UHD (3840 x 2160)

Resolution Support

VGA (640 x 480) to 4K UHD (3840 x 2160)

Brightness (ANSI lumens)

3000 ANSI Lumens

Contrast Ratio (FOFO)

30,000:1 (Dynamic Iris)

Display Color

30 Bits (1.07 billion colors)

Native Aspect Ratio

Native 16:9 (6 aspect ratio selectable)

Light Source

Lamp

Light Source Wattage

245W

Light Source Life

Normal 4,000 hours
Eco 10,000 hours
SmartEco 15,000 hours

Throw Ratio

1.13 - 1.47 (100" @ 8.2 ft / 2.5 m)

Zoom Ratio

1.3x

Lens

F/# = 1.9 - 2.47, f = 12 - 15.6 mm

Lens Shift

Vertical +10%

Keystone Adjustment

1D, (Auto) Vertical +/- 30 degrees

Projection Offset

100%

Clear Image Size (Diagonal)

40"-200"

Image Size

30"-300"

Horizontal Frequency

15K-135K Hz

Vertical Scan Rate

23-120Hz

Picture Mode

Bright / Living Room / Cinema / Sports / Game / (3D) / User 1 / HDR / HLG

Color Wheel Segment

4 segment (RGBWYC)

Color Wheel Speed

2D: 96Hz; 100Hz; 120Hz, 3D max 120Hz

Rec.709 Coverage

98%

Speaker

2x 5W Chamber Speaker

HDMI

x2 (HDMI 2.0b/HDCP2.2)

USB Type A

x1 (5V/2.5A power)
x1 (Media Reader, FW Download)

USB Type mini B

x1 (FW Download, Service)

Audio out (3.5mm Mini Jack)

x1

Audio out (S/PDIF)

x1 (Only support 2-channel audio)

RS232 (DB-9pin)

x1

DC 12V Trigger (3.5mm Jack)

x1

IR Receiver

x2 (Front/Top)

Security Bar

Security Bar / Kensington anti-theft lock slot

HDR

Yes (HDR10, HLG)

Motion Enhancer (MEMC)

Yes

CinemaMaster Video +

Yes

CinemaMaster Audio+2

Yes

HDTV Compatibility

720p 50/60Hz, 1080i 50/60Hz, 1080p 24/25/30/50/60Hz, 2160p 23/24/25/30/60Hz

3D Compatibility

Frame Packing: Up to 1080p 24Hz
Side by Side: Up to 1080p 60Hz
Top Bottom: Up to 1080p 60Hz

Power Supply

VAC 100 - 240 (50/60Hz)

Typical Power Consumption

Max 350W, Normal 340W, Eco 280W

Standby Power Consumption

0.5W Max. at 100 - 240VAC

Acoustic Noise (Typ./Eco.)

30/28 dBA (Silence mode)

Operating Temperature

32 - 104 Degree F (0-40 Degree C)

OSD Language

Arabic/ Bulgarian/ Croatian/ Czech/ Danish/ Dutch/ English/ Finnish/ French/ German/ Greek/ Hindi/ Hungarian/ Italian/ Indonesian/ Japanese/ Korean/ Norwegian/ Polish/ Portuguese/ Romanian/ Russian/ Simplified Chinese/ Spanish/ Swedish/ Turkish/ Thai/ Traditional Chinese (28 Languages)

Battery Info

Required, included

Battery Material

Battery Quantity

Battery Type

AAA

Dimensions (W x H x D)

12 x 4 x 9" (312 x 110 x 225mm)

Weight

9.2 lbs (4.2kg)
